Decision tree in a recursive way

Source: R/recursive_tree.R

Decision tree in a recursive way

recursive_tree(
  data = data,
  Y = "Y",
  modele = NULL,
  kill = NULL,
  index = NULL,
  verbose = TRUE,
  plot = TRUE,
  main = NULL,
  sub = NULL,
  lang = c("en", "fr"),
  all = FALSE,
  digits = getOption("digits") - 3
)

Arguments

data

the dataset including the response
Y

the name of the response
modele

(optional) vector of names of covariates allowed in the tree
kill

vector of the names to kill (variables won't be used in the tree)
index

to give a number to the plot
verbose

boolean to print the tree parameters
plot

boolean to plot the tree
main

the main title if plot=TRUE
sub

the subtitle (if NULL it is automatically added)
lang

the language for the automatic subtitle in the plot
all

Logical. If TRUE, all nodes are labeled, otherwise just terminal nodes.
digits

number of digits for legend of the leaves

Value

returns the tree as an "rpart" object and the modele as a vector of the names of the covariates the tree could have used (to give as an input of the function).

modele

vector of the names of the covariates the tree could have used

tree

the regression tree as an "rpart" object

Examples

data <- mtcars
main = "Regression tree of cars consumption (in mpg)"
mytree = recursive_tree(data = data, Y = "mpg", main = main, verbose = FALSE)

#> Warning: graphical parameter "cin" cannot be set
#> Warning: graphical parameter "cra" cannot be set
#> Warning: graphical parameter "csi" cannot be set
#> Warning: graphical parameter "cxy" cannot be set
#> Warning: graphical parameter "din" cannot be set
#> Warning: graphical parameter "page" cannot be set
# want to try without cylinder and disp
mytree2 = recursive_tree(data = data, Y = "mpg", kill = c("cyl", "disp"),
modele = mytree$modele, main = main, verbose = FALSE)

#> Warning: graphical parameter "cin" cannot be set
#> Warning: graphical parameter "cra" cannot be set
#> Warning: graphical parameter "csi" cannot be set
#> Warning: graphical parameter "cxy" cannot be set
#> Warning: graphical parameter "din" cannot be set
#> Warning: graphical parameter "page" cannot be set
